prelude

ob·​liv·​i·​ate
(transitive) To forget; to wipe from existence.

Øbliviate is a FRL TKL keyboard layout featuring an o-ring mount within a single monoblock design. The concept behind Øbliviate is to deliver a 60% O-ring keyboard experience by dividing the alphanumeric cluster and navigation cluster into separate sections. The hypothesis behind this design is that by having separate sections between each cluster, the inner wall will create a friction fit with the PCB and plate, impacting both sound and typing feel.Interest check is now open. Your input will be very valuable to determine the price.

prelude

ob·​liv·​i·​ate
(transitive) To forget; to wipe from existence.

Øbliviate is a FRL TKL keyboard layout featuring an o-ring mount within a single monoblock design. The concept behind Øbliviate is to deliver a 60% O-ring keyboard experience by dividing the alphanumeric cluster and navigation cluster into separate sections. The hypothesis behind this design is that by having separate sections between each cluster, the inner wall will create a friction fit with the PCB and plate, impacting both sound and typing feel.Interest check is now open. Your input will be very valuable to determine the price.

prelude

ob·​liv·​i·​ate
(transitive) To forget; to wipe from existence.

Øbliviate is a FRL TKL keyboard layout featuring an o-ring mount within a single monoblock design. The concept behind Øbliviate is to deliver a 60% O-ring keyboard experience by dividing the alphanumeric cluster and navigation cluster into separate sections. The hypothesis behind this design is that by having separate sections between each cluster, the inner wall will create a friction fit with the PCB and plate, impacting both sound and typing feel.Interest check is now open. Your input will be very valuable to determine the price.

prelude

ob·​liv·​i·​ate
(transitive) To forget; to wipe from existence.

Øbliviate is a FRL TKL keyboard layout featuring an o-ring mount within a single monoblock design. The concept behind Øbliviate is to deliver a 60% O-ring keyboard experience by dividing the alphanumeric cluster and navigation cluster into separate sections. The hypothesis behind this design is that by having separate sections between each cluster, the inner wall will create a friction fit with the PCB and plate, impacting both sound and typing feel.Interest check is now open. Your input will be very valuable to determine the price.

DESIGN

DESIGN

DESIGN

Specifications

Specifications

Specifications

FRL TKL Layout

Gummy o-ring mount

6.5° typing angle

22.672mm effective keyboard height

Aluminum 6063, Brass Weight, Brass Accent

1.6mm FR4 with optional add-ons Aluminium, Polycarbonate, POM, Carbon Fiber 1.5mm plate

In house design PCB obliviate FRLTKL 1.6mm thickness solder or hotswap - configurable with QMK/VIA

INCLUDED KIT

INCLUDED KIT

INCLUDED KIT

Keyboard case: (Case, Weight, Accent)

1.6mm FR4 plate

1.6mm Hotswap/Solder PCB; layout information will be shared later

Daughterboard, Bridge, Flate flexible cable

1x O-ring (50a) for alphanumeric cluster and nav cluster

4x Custom-designed rubber feet

Plate support switch comb/fork

Hand-carry keyboard bag

Other accessories
